AvailableCNC Lathe

Used Haitong CK 5243 E CNC Double-Column Vertical Lathe

Haitong CK 5243 E CNC double-column vertical lathe, a 4.3-metre-class machine built in 2022 and equipped with the Siemens 828 D CNC control system. The machine carries a 3600 mm worktable rated for 32,000 kg and a maximum turning diameter of 4300 mm, with a maximum workpiece height of 2800 mm. It is fitted with a dual tool post configuration in the original CNC arrangement and a 55 kW servo main motor. Two identical units are available.

Machine Code: CL2609143
Year: 2022
Location: China
Usage Hours: On request

Contact access

Dealer contact details are distinct from the machine location. Availability and prices require confirmation with the seller.

Loading…

Main Specifications

Machine type	CNC double-column vertical lathe
Worktable diameter	3600 mm
Maximum turning diameter	4300 mm
Maximum workpiece height	2800 mm
Maximum workpiece weight	32000 kg
Tool post configuration	Dual tool post, original CNC
Control system	Siemens 828 D
Main motor power	55 kW servo main motor
Year of manufacture	2022
Quantity available	Two identical units
Brand	Haitong
