Used Guangdong Yiji VTC 800 High-Speed CNC Vertical Lathe (2023, 2 Units)
Used Guangdong Yiji VTC 800 high-speed CNC vertical lathe available from China stock. Two identical units, 90% new.
- Machine Code
- CL260879
- Year
- 2023
- Location
- China
- Usage Hours
- On request
Accessories
Chain chip conveyor, nitrogen balancing.
Main Specifications
| Max turning diameter | 800 mm |
|---|---|
| Machining height | 720 mm |
| Spindle speed | 25-600 rpm |
| Spindle motor power | 22 kW |
| Spindle nose | A 2-11 |
| Chuck size | 25 inch |
| Turret stations | 8 |
| Guideway | Hiwin 55 mm heavy-duty roller linear guideway on two axes |
| Year | 2023 |
| Machine Type | CNC vertical lathe |
| Brand And Model | Guangdong Yiji VTC 800 |
| Chuck Type | hydraulic |
| Turret | Taiwan Maikun heavy-duty hydraulic turret |
| Guideway Configuration | Hiwin 55 mm heavy-duty roller linear guideway on two axes |
| Controller | KND K 2000 (large-screen bus absolute system) |
| Spindle Type | heavy-duty mechanical spindle |
| Chip Conveyor | chain-type chip conveyor |
