AvailableGrinding Machine

Used Okamoto OGM 350 EXB Grinding Machine

Japan Okamoto precision cylindrical grinding machine. Model OGM 350 EXB. Swing over table: 320 mm, grinding length: 600 mm, worktable rotation angle: -4° to +11°, grinding wheel size: 355 x 38 x 127 mm, wheel spindle rotation angle: ±30°, workpiece headstock rotation angle: -90° to +30°, spindle and tailstock taper: Morse 4, machine weight: 3500 kg, voltage: 3-phase 200 V, total power: 20 KVA. Parameters subject to actual machine.

Machine Code: GR260602
Year: On request
Location: China
Usage Hours: On request

Email Inquiry

Main Specifications

Maximum swing over worktable	320 mm
Grinding length	600 mm
Worktable rotation angle	-4° to +11°
Grinding wheel size (OD x Width x Bore)	355 x 38 x 127 mm
Wheel spindle rotation angle	±30°
Workpiece headstock rotation angle	-90° to +30°
Spindle and tailstock taper	Morse 4
Machine weight	3500 kg
Voltage	3-phase 200V
Total power	20 KVA
Machine Type	Cylindrical Grinding Machine
Brand	Okamoto
Model	OGM 350 EXB
