AvailableVertical Machining Center

Used Zhiyuan Smart-T 740 Vertical Drilling and Tapping Center with Mitsubishi M 80 Control

Zhiyuan Smart-T 740 vertical drilling and tapping center, built by Dongguan Zhiyuan CNC Equipment Manufacturing Co., Ltd. in April 2024, offered in near-new condition with ten units available. Each machine is equipped with the Mitsubishi M 80 CNC control system and a 21-station servo tool magazine, paired with a BT30 spindle running up to 20,000 rpm for high-speed drilling, tapping and light milling work. Rated power is 15 kW, overall dimensions are 1800 x 2200 x 2500 mm, and net weight is 3.5 t. Compact, fast-cycling vertical drilling and tapping platform suited to batch production of small and medium-sized parts.

Machine Code: VMC2610210
Year: 2024
Location: China
Usage Hours: On request

Accessories

21-station servo tool magazine

Contact access

Dealer contact details are distinct from the machine location. Availability and prices require confirmation with the seller.

Loading…

Main Specifications

Machine type	Vertical drilling and tapping center
Model	Smart-T 740
Manufacturer	Dongguan Zhiyuan CNC Equipment Manufacturing Co., Ltd.
Manufacturing date	2024-04
Control system	Mitsubishi M 80
Tool magazine capacity	21 stations (servo tool magazine)
Spindle taper	BT30
Spindle speed	20,000 rpm
Power	15 kW
Machine dimensions	1800 x 2200 x 2500 mm
Machine weight	3.5 t
Quantity available	10 units
Brand	Zhiyuan
Year of manufacture	2024
