DisponívelVertical Machining Center

Two Nearly New Taiqun Precision TV 856 S Vertical Machining Centers with FANUC MF Plus

Two nearly new Taiqun Precision TV 856 S vertical machining centers, manufactured in December 2024 and installed in 2025, with actual use of about 3 months (over 900 hours). Equipped with 30 kg/cm² spindle through-spindle coolant, BT40 belt-driven 10000 rpm spindle, 24-tool arm-type ATC, three-axis HIWIN roller linear guideways, and the latest FANUC MF Plus control. X/Y/Z travel: 800 x 550 x 600 mm; worktable 1000 x 500 mm. Parameters are for reference only, subject to actual machine on site.

Código da Máquina: VMC260803
Ano: 2024
Localização: China
Horas de Uso: Sob consulta

Acessórios

Spindle through-spindle coolant system (30 kg/cm²)

Consulta por E-mail

Principais Especificações

Spindle taper	BT40
Spindle speed	10000 rpm
Spindle power	11/15 kW
X/Y/Z travel	800 x 550 x 600 mm
Worktable size	1000 x 500 mm
Tool magazine capacity	24 tools
Guideway	HIWIN roller linear guideway (three axes)
Control system	FANUC MF Plus
Year of manufacture	2024
Working hours	Approximately 900 hours
Quantity	2 units
