DisponívelCNC Lathe

Used DMG MORI Ecoturn 450 CNC Lathe with Siemens 840D sl

Shared good platform, for sale from stock: DMG MORI Ecoturn 450 CNC lathe. Equipped with Siemens 840D sl control system, belt-driven spindle 4000 rpm, maximum swing diameter 650 mm, maximum turning diameter 400 mm, X-axis travel 265 mm, Z-axis travel 650 mm, spindle bore diameter 65 mm, 10-inch chuck (250 mm), tailstock, 12-station servo turret, linear guideways on all axes, X/Z rapid traverse speed 30 m/min, with chip conveyor. Trial cutting accuracy 0.005 mm. Year of manufacture: 2015.

Código da Máquina: CL260887
Ano: 2015
Localização: China
Horas de Uso: Sob consulta

Acessórios

Tailstock Chip conveyor

Consulta por E-mail

Principais Especificações

Maximum swing diameter	650 mm
Maximum turning diameter	400 mm
X-axis travel	265 mm
Z-axis travel	650 mm
Spindle bore diameter	65 mm
Chuck size	250 mm (10 inch)
Spindle speed	4000 rpm
Turret stations	12
Rapid traverse speed (X/Z)	30 m/min
Trial cutting accuracy	0.005 mm
