Used Neway 3080 H Z Heavy-Duty Gantry Milling Machine with FANUC Plus Control

Used Neway 3080 H Z heavy-duty gantry milling machine with FANUC Plus control, almost new condition, available for inspection in Wuxi factory. Equipped with square ram 450 x 450 mm, automatic milling head, tool magazine, and 50 kg through-spindle coolant. X/Y/Z travel 8500 x 4600 x 1500 mm, worktable 3000 x 8000 mm, door width 4200 mm, door height 1900 mm, table load capacity 40 tons.

Código da Máquina: PM260734
Ano: Sob consulta
Localização: Wuxi, China
Horas de Uso: Sob consulta

Acessórios

Automatic milling head, tool magazine, 50 kg through-spindle coolant

Consulta por E-mail

Principais Especificações

X/Y/Z travel	8500 x 4600 x 1500 mm
Worktable size	3000 x 8000 mm
Door width/height	4200/1900 mm
Table load capacity	40 T
Ram cross section	450 x 450 mm
Through-spindle coolant pressure	50 kg
