DisponívelMachining Center

Used She Hong CNC-2015 L Gantry Type Machining Center

Used She Hong CNC-2015 L gantry type machining center from Taiwan. The machine is equipped with FANUC MF control, high-end separate drive units, Alpha motors, two linear guideways and one box guideway, linear scales, 190 mm diameter BT50 gear spindle with 6000 rpm, worktable 1400 x 2000 mm, X/Y/Z travel 2200/1500/800 mm. Hydraulic unit and chip conveyor included. The machine has been installed and lightly used. Inspections are welcome.

Código da Máquina: MC260853
Ano: 2015
Localização: China
Horas de Uso: Sob consulta

Acessórios

Hydraulic unit, oil cooler, linear scales, dual screw and chain-type chip conveyor

Consulta por E-mail

Principais Especificações

Control system	FANUC MF
Spindle taper	BT50
Spindle speed	6000 rpm
Worktable size	1400 x 2000 mm
Gantry width	1650 mm
Gantry height	1000 mm
Spindle nose to table	930 mm
X/Y/Z travel	2200/1500/800 mm
Guideways	Two linear guideways and one box guideway
Machine Type	Gantry Machining Center
Brand	She Hong
Model	CNC-2015 L
Guideway Configuration	Two linear guideways and one box guideway
Spindle Diameter	190 mm
Gear Head	Yes
Hydraulic Unit	Included
Chip Conveyor	Built-in dual screw and chain chip conveyor
