Used ROKU-ROKU MEGA-SS 400 Ultra-Precision Micro Machining Center with FANUC 31i-B 5-Axis

ROKU-ROKU MEGA-SS 400 ultra-precision micro machining center, original from Japan. Gantry-type high-rigidity structure with mineral casting base. Equipped with FANUC 31i-B 5-Axis control system, HSK-E 25 spindle holder, 20-tool arm-type ATC, and 40,000 rpm oil-cooled spindle. Suitable for micro-hole drilling (min. φ0.01 mm drill) and ultra-small end mills (R 0.05).

Código da Máquina: MC260778
Ano: 2019
Localização: China
Horas de Uso: Sob consulta

Acessórios

Optional: Swiss Hexagon tool setter

Consulta por E-mail

Principais Especificações

Spindle speed	40000 rpm
Spindle power	4.0 kW
X/Y/Z travel	410 x 330 x 200 mm
Worktable size	450 x 350 mm
Table load capacity	200 kg
Tool magazine capacity	20
Rapid traverse (X/Y)	32 m/min
Rapid traverse (Z)	24 m/min
Machine weight	2500 kg
Year	2019
Machine Type	Ultra-Precision Micro Machining Center (Gantry type)
Controller	FANUC 31 i-B 5
Machine Structure	Gantry type high-rigidity bed
Accessory	Swiss Hexagon tool setter (optional)
Tool Holder Specification	HSK-E 25
Applicable Tools	Minimum φ0.01 micro drill
Cutting Feed	1~10000 mm/min
Applicable Industry	Semiconductor fixtures
Minimum Hole Diameter	0.01 mm
Machine Base Material	Mineral casting
